Water Distillation Units

The Water Distillation Units (Single Stage Distillation Unit) deliver high-purity distilled water for analytical, clinical, and industrial laboratory applications. Designed with a horizontal boiler and condenser constructed from high-grade borosilicate glass, this unit features a silica-sheathed (quartz) heating element that ensures efficient, contaminant-free thermal distillation. Operating with an output distillate temperature maintained between 65°C to 75°C, the system includes a rust-free powder-coated stand, a constant level device, an energy-saving cooling water recirculation mechanism, and a low water sensor with automatic safety shut-off to protect glass components against heating failure. Ideal for analytical chemistry reagent prep, media preparation, instrumental analysis support, and general laboratory washing routines. Suitable for pharmaceutical, biotechnology, healthcare, environmental testing, and academic research industries. Supplied by Edulabs.

Storage Instructions

Store the distillation unit in a clean, dry, climate-controlled equipment room when not in operation.
Drain all residual water from the borosilicate glass boiler, condenser, and tubing before storage.
Protect glass components with cushioned dust covers or original packaging during transport or long-term storage.
Store electrical components, quartz heating elements, and sensors away from high humidity or corrosive vapor zones.
Avoid placing heavy objects on top of the powder-coated support frame or glass boiler assembly.
Keep electrical cords organized and free from strain or sharp bends.

Safety Information

Ensure the unit is connected to a properly grounded electrical outlet matching specified power requirements.
Do not operate the distillation unit without verifying continuous cooling water flow through the condenser.
Avoid touching hot borosilicate glass surfaces, steam outlets, or distillate lines during or immediately after operation.
Wear heat-resistant gloves, protective eye gear, and laboratory coats when working near active distillation units.
Ensure the low water sensor and automatic cutout functionality are periodically tested before routine production runs.
Regularly descaling the borosilicate boiler using approved mild descaling solutions prevents mineral scale buildup on quartz heaters.
Turn off electrical power supply and main water inlet line prior to performing maintenance, cleaning, or component replacement.

Category: Distillation

Description
Reviews (0)

The Water Distillation Units (Single Stage Distillation Unit) engineered by Edulabs deliver reliable, continuous production of high-purity distilled water essential for rigorous laboratory testing and analytical protocols. Designed for single-stage thermal distillation, this unit removes inorganic salts, pyrogens, heavy metals, and organic impurities from feed water.

The complete set features a horizontal-type boiler and high-efficiency condenser manufactured entirely from high-purity borosilicate glass. Borosilicate glass construction ensures that boiling water and high-purity steam remain completely free from metallic leaching or ion contamination. Thermal energy is supplied by a removable silica-sheathed (quartz) heater, which provides rapid heat transfer and high corrosion resistance against scaling.

Operational safety and energy efficiency are key design features. An efficient condenser design ensures that distillate temperature is maintained at an optimal 65°C to 75°C. Cooling water from the condenser is automatically re-circulated back into the boiling chamber, conserving energy and reducing raw water consumption.

To safeguard the glass boiler and quartz element, the unit is fitted with an integrated low water sensor and an automatic cutoff mechanism. If raw water supply fails or drops below minimum thresholds, the system automatically shuts off power to the heater, preventing glass fracture or element burnout. The entire apparatus is mounted on a powder-coated stand that provides rust-free operation, structural stability, and an attractive, lustrous laboratory appearance.

Edulabs manufactures these Single Stage Distillation Units in output capacities of 1.5, 2.5, and 4.0 liters per hour, making them a cost-effective choice for modern scientific, industrial, and educational laboratories.

Key Features

Complete set with horizontal borosilicate glass boiler and high-efficiency glass condenser.
Removable silica-sheathed (quartz) heating element for efficient heating and minimal scaling.
Output distillate maintained at an optimal temperature range of 65°C to 75°C.
Powder-coated support stand for rust-free durability and high mechanical stability.
Automatic power shut-off system triggered when water levels drop below heating elements.
Energy-saving design that recirculates heated cooling water into the boiling chamber.
Low water sensor protects expensive glass components from thermal burnout during water failure.
Integrated constant level device maintains steady boiling volume during continuous operation.
Produces high-purity pyrogen-free distilled water suitable for analytical applications.
Available in flow output capacities of 1.5 L/Hr, 2.5 L/Hr, and 4 L/Hr.

Technical Specifications

Parameter	Specification
Product Name	Water Distillation Units
Material	Borosilicate Glass (Boiler & Condenser) / Quartz (Heater) / Powder-Coated Steel (Stand)
Heater Type	Removable Silica Sheathed (Quartz) Heater
Distillate Temperature	65°C to 75°C
Safety Features	Low Water Sensor, Automatic Cutoff System, Constant Level Device
Construction	Horizontal boiler design with recirculating condenser on stand with clamps
Water Conservation	Condenser cooling water re-circulated to boiling chamber
Output Capacity	1.5 Ltr/Hr / 2.5 Ltr/Hr / 4.0 Ltr/Hr
Application	High-purity laboratory water distillation for analytical testing
Grade	Laboratory Equipment Grade

Available Models

Item Code	Output Capacity Ltr/Hr	Pack of
SL.SSD.1	1.5	1
SL.SSD.2	2.5	1
SL.SSD.3	4	1

Applications

High-purity reagent and standard solution preparation in analytical chemistry.
Preparation of microbiological culture media and tissue culture reagents.
Feedwater supply for laboratory glassware washing and rinsing machines.
Supply for clinical pathology analyzers and automated diagnostic equipment.
General analytical testing in environmental and wastewater analysis labs.
Quality control testing in food, beverage, and dairy testing facilities.
Pharmaceutical formulation testing and analytical assay support.
Educational laboratory experiments in chemistry and life sciences.
Solvent preparation for spectroscopy and general wet chemistry.
Industrial quality assurance testing requiring mineral-free water.

Note

Edulabs also offers a comprehensive range of laboratory glassware, laboratory plasticware, laboratory chemicals, laboratory instruments, laboratory equipment, scientific apparatus, educational laboratory equipment, and customized laboratory solutions for educational institutions, research laboratories, pharmaceutical industries, healthcare facilities, biotechnology laboratories, environmental testing laboratories, food and beverage laboratories, and industrial quality control laboratories. Contact Edulabs for bulk orders and OEM requirements.
